| GL18-LX(S.C)10CD down (Top) discharge 1Phase DC fan motor 10 Speed | Model | Vol./Fre. | Motor Power | Air flow | Full Pres. | Fan Speed | |
| GL18-LX(S.C)10CD | 220-240V/50-60Hz | 1.1kw | 18000m3/h 10600CMF | 240Pa | 10 inverter grade speed | ||
| Dimension of air outlet | Physical dimension | Pad sizes | Noise(dba 1m) | Net.Wei. | Op. Wei. | ||
| 660*660mm (26”X26”) | 1150x1150x960mm 45.3"x45.3"x37.8" | 775x670x100mm 30.5"x26.4"x4" | ≤74 | 80kgs | 110kgs | ||
| Airflow (fan)style | Rate Current | Water consumption | Water tank capacity | Water drain | Effective area | ||
| Centrifigual | 5(A) | 40-60(l/h) | 45(L) | Auto drain | 100-200(m2) 1000-2000sq.ft | ||
| GL18-LX(S.C)10CD Side discharge 1phase DC fan motor 10 Speed | Model | Vol./Fre. | Motor Power | Air flow | Full Pres. | Fan Speed | |
| GL18-LX(S.C)10CD | 220-240V/50-60Hz | 1.1kw | 18000m3/h 10600CMF | 240Pa | 10 inverter grade speed | ||
| Dimension of air outlet | Physical dimension | Pad sizes | Noise(dba 1m) | Net.Wei. | Op. Wei. | ||
| 660*660mm (26”X26”) | 1150x1150x960mm 45.3"x45.3"x37.8" | 775x670x100mm 30.5"x26.4"x4" | ≤74 | 80kgs | 110kgs | ||
| Airflow (fan)style | Rate Current | Water consumption | Water tank capacity | Water drain | Effective area | ||
| Centrifigual | 5(A) | 40-60(l/h) | 45(L) | Auto drain | 100-200(m2) 1000-2000sq.ft | ||
